INSTALLATION
2-48 L025317 Issue 1 March 2011
To extend the marking field in Dynamark 3, move the object in the opposite
direction to the movement outside the marking field.
Marking starts as the product marking field enters the marking area.
Note: Moving the mark on the screen, whether in the real or extended fields, can
move the mark on the product. First set the ideal position of the mark on
the screen, then adjust the product detector (print go) or change the encoder
delay to set the actual mark position onto the product.
Marking area
Product
Marking field on product
Product movement direction
