SECTION 2 BASIC OPERATION
22 0855849enf 6/08
An umbilical (1), which consists of an ink line, vacuum line, and
electrical line, connects each printhead to the print station.
The operator inserts an ink bottle through the ink door (2). The ink
is melted and transported to the printhead through the ink line. The
printhead ejects droplets of ink onto your product or package.
2
1
