SECTION 2 BASIC OPERATION
0855849enf 6/08 21
1.0 Basic Components
The coder consists of the print station (1), umbilical (2), printhead
(3), and any options installed.
The print station consists of the user interface module (4) and
enclosure (5). The enclosure is the cabinet that houses the electrical
components, vacuum pressure controller, and ink delivery module.
Mounted to the top of the enclosure is the user interface module,
consisting of a keypad and display, which are used to operate,
program, and monitor the coder.
1
2
3
4
5
