Instructions for use | Atlan A100 (XL), A300 (XL), A350 (XL) SW 2.1n 137
Tests
7.5.6.5 Calibrating the inspiratory O2 sensor
During calibration, the sensor must be exposed to ambient air, i.e., 21 % oxygen
concentration. Fluctuating oxygen concentrations must be avoided. The following
notes must be adhered to:
– Do not fill vaporizers during the calibration.
– Close all the flow control valves.
– Do not blow into the sensor.
– Do not use any disinfectants.
1. If the O
2 sensor is to be calibrated despite a valid calibration, touch the
Calibrate button.
If the validity of the last calibration has expired, the prompt to perform a
calibration appears automatically.
2. Touch the button and follow the instructions on the screen.
3. Turn the O
2 sensor counterclockwise and remove it.
Place the O
2 sensor as shown (1).
4. Take the sealing cap (2) from the holder (3).
Seal the sensor port with the sealing cap.
5. Follow the instructions on the screen.
The device will perform the calibration.
3967939674
1
