Overview
3.2.5 Additional operation modes
Indication of availability
The available equipment for the main devices is shown in the tables below and is
identified as follows:
3.2.6 Monitoring functions
The device can monitor the following:
– Airway pressure
– Minute volume, tidal volume
– Inspiratory O
2 concentration
– Expiratory O
2 concentration (only available with the integrated patient-gas
measurement module)
– Inspiratory and expiratory anesthetic gas concentrations (only available with the
integrated patient-gas measurement module)
– Inspiratory and expiratory CO
2 concentrations (only available with the integrated
patient-gas measurement module)
– Inspiratory and expiratory N
2O concentrations (only available with the integrated
patient-gas measurement module)
– Respiratory rate, apnea (derived from pressure, flow, and CO
2)
– Occurrence of anesthetic gas mixtures (only available with the integrated
patient-gas measurement module)
– Lack of fresh gas in the breathing system and the breathing circuit
Indicator Meaning
The main device has this equipment.
The equipment is available as an option.
--- The equipment is not available.
Operation mode Main device
A100 (XL) A300 (XL) A350 (XL)
External fresh-gas outlet
Pause ---
1)
1) Pause must be activated in the system setup.
1)
Monitoring
2)
2) Only for devices with integrated PGM.
3)
3) Pause must be deactivated in the system setup.
3)
CBM mode
