Dräger CMS User Manual

Dräger CMS Analyzer 41
Preparing for use
6.2 Checking the battery capacity
 Move sliding switch to position 1.
The analyzer performs a self-test.
 All display elements are activated:
The battery voltage is checked during the
self-test:
The analyzer switches off when the battery voltage has dropped below the minimum capacity
(display: Battery empty).
Fit new batteries, page 40.
 Move sliding switch to position 0.
4 battery symbols (see example)
=
batteries fully charged;
corresponds to approx. 450 minutes of
measurement.
1 battery symbol
=
batteries must be replaced as their
capacity is too low for further
measurements.
00922837.eps
0
1
2
3
0
1
2
3
01022837.eps
01122837_4en.eps
function test
please wait

Dräger CMS Specifications

General

Brand	Dräger
Model	CMS
Category	Measuring Instruments
Language	English
