Dräger CMS

Dräger CMS Analyzer 63
Technical data
1) Use of the analyzer outside the specified ambient conditions may result in incorrect measurement.
Please contact the nearest Dräger office in conjunction with extreme ambient conditions.
2) Only classified by Underwriters Laboratories Inc. with regard to intrinsic safety for explosion hazard
areas.
Weight
Analyzer without batteries 640 g
Analyzer with batteries 730 g
Dimensions of analyzer [mm] 215 x 105 x 65
Approvals
For analyzer set (Part No. 6405300):
ATEX approval,
BVS 03 ATEX E 209X
UL USA,
Class 1, Div. 1, Groups A, B, C, D,
Temp. Code T4, 2P911)
2)
UL Canada,
Class 1, Div. 1, Groups A, B, C, D,
Temp. Code T4, 2P911)
2)
CSA Canada,
Class 1, Div. 1, Groups A, B, C, D,
T4 Ex ia
CE marking Electromagnetic compatibility
(Directive 2014/30/EU)
ATEX
(Directive 2014/34/EU)
04822837.eps
215
105
0 1 2 3
0 1 2 3
0158
II 2G Ex ib IIC T4 Gb
BVS 03 ATEX E 209X
