24 Technical manual | X-am® 3500/8000
Operation
If the measuring range is exceeded significantly at the CatEx channel (very high
concentration of flammable materials), a blocking alarm is triggered. This CatEx
blocking alarm can be acknowledge by switching the gas detector off and then on
again in fresh air.
X-am 8000 only: This does not apply in the case of an activated over range for
methane.
4.7.5 Deleting (application) peaks
1. Select in measuring mode.
2. Select Clear app. peak and confirm the dialog.
The function must be activated in the quick menu. Alternatively, this function can
also be called via the menu.
4.8 Calling the Quick Menu
The Dräger CC-Vision software can be used to save up to 6 preferred features.
The following features are default settings:
– Device information
– Switch between day and night mode
– Display messages
– Display shift peaks
– Display application peaks
– Delete application peaks
To open the quick menu:
1. Select in measuring mode.
2. Select and confirm the desired feature.
4.9 Opening information
1. Select > Info in measuring mode.
The following options are available:
Option Description
Messages The pending warnings and errors are
displayed.
Device information Device information and information
about the Bluetooth® module (optional,
X-am 8000 only) is displayed (e.g. MAC
address, serial number, firmware ver-
sion etc.).
