Technical manual | X-am® 3500/8000 63
Configuration
7 Configuration
7.1 Standard gas configuration
Different settings can be selected to meet customer requirements on delivery. The
current setting can be checked and changed with the Dräger CC-Vision PC
software.
The Dräger CC-Vision PC software can be downloaded at
www.draeger.com/software.
DrägerSensor Measuring
range
Alarm A1 Alarm A2
threshold -
ackno
wledg
eable
- latch-
ing
threshold -
acknow
ledge-
able
- latching
DUAL IR Ex/CO
2:
DUAL IR Ex (e.g.
methane) [%LEL]
DUAL IR CO
2 [Vol%]
0 ... 100
0 ... 5
20
0.5
-
40
1.0
-
IR Ex (e.g. methane)
[%LEL]
0 ... 100 20 - 40 -
IR CO
2 [Vol%]
0 ... 5 0.5 - 1.0 -
XXS O
2 [Vol%]
1)
0 ... 25
↓19.5 | ↑22.
5
- ↓19 | ↑23 -
XXS O
2 100 [Vol%]
0 ... 100 ↓18.5 | ↑24 - ↓17.5 | ↑25 -
XXS O
2 / CO LC
[Vol%]/[ppm]
0 ... 25 O2
0 ... 2,000
CO
↓19 | ↑23
O2
30 CO
-
-
↓17 | ↑24
O
2
60 CO
-
-
XXS O
2 / H2SLC
[Vol%]/[ppm]
0 ... 25 O2
0 ... 100 H2S
19 O
2
5H2S
-
-
23 O
2
10 H2S
-
-
XXS O3 [ppm]
0 ... 10 0.1 - 0.2 -
XXS CO LC [ppm]
0 ... 2,000 30 - 60 -
XXS CO HC [ppm]
0...10,000 600 - 1,200 -
XXS CO H
2 CP [ppm]
0 ... 2,000 30 - 60 -
XXS H
2 [ppm]
0 ... 2,000 200 - 400 -
XXS H
2 HC [Vol%]
0 ... 4 0.8 - 1.6 -
XXS H
2S [ppm]
0 ... 200 5 - 10 -
XXS H
2S LC [ppm]
0 ... 100 5 - 10 -
XXS H
2S HC [ppm]
0 ... 1,000 10 - 20 -
XXS H
2S CO [ppm] 0 ...200 H2S
0 ... 2,000
CO
5 H
2S
30 CO
-
10 H
2S
60 CO
-
XXS H
2S LC / CO LC
[ppm]
0 ... 100 H2S
0 ... 2,000
CO
5 H
2S
30 CO
-
10 H
2S
60 CO
-
