Technical manual | X-am® 3500/8000 25
Operation
4.10 Measuring
4.10.1 Special features when measuring with the pump
NOTICE
Magnetic media may be damaged!
The pump adapter and calibration adapter contain a magnet which may delete data
from a magnetic stripe.
► Do not bring magnetic media (e.g. credit cards) into close proximity to the pump
adapter or calibration adapter.
– Use the dust and water separators when taking measurements with the pump.
– Following a bump test with aggressive gases (such as biogas or chlorine), flush
the pump with clean air for several minutes to extend the service life of the
pump.
Gas statistics The following gas statistics are avail-
able:
–Select Shift peak to display the
exposure peaks for all gasses.
–Select Application peak to display
the application peaks for all gasses.
–Select TWA values to display the
available TWA values for all gasses.
–Select STEL values to display the
available STEL values for all gasses.
Intervals The following intervals are available:
– Select the bump test interval (Bump
test interval) to display the days
remaining until the next bump test for
all channels. For details, select and
confirm the respective channel.
–Select Calibration interval to dis-
play the days remaining until the next
calibration for all channels. For
details, select and confirm the
respective channel.
–Select Life time to display the
remaining life time.
Capture ranges Capture ranges are displayed.
Battery The battery state of charge is displayed
(large).
Approvals
(X-am 8000 only with the Bluetooth®
module)
Approval information is displayed (e-
Label).
Option Description
