Dräger Polaris 600

Instructions for use Polaris 600 47
Operation
Status LEDs
The description of this function applies to both the
light control panel and the wall-mounted control
panel. Only the light control panel is shown in the
illustrations.
Status LED for monitoring a light
The status LED (A) for monitoring the light is
situated directly next to the key.
– The status LED (A) is lit green.
The light is in operation.
– The status LED (A) is not lit.
The light is in standby mode.
– The status LED (A) is lit orange.
There is a light system fault, see "Fault –
Cause – Remedy" on page 67.
Status LED for monitoring the power supply
The status LED (A) for monitoring the power
supply for the light system is located to the left of
the key.
– The status LED (A) is lit green.
The light is being supplied with mains power.
– The status LED (A) is lit orange.
The light is being supplied with emergency
power.
– The status LED (A) is not lit.
The light is not being supplied with power.
26399
A
26477
A
