Dräger Polaris 600

Operation
54 Instructions for use Polaris 600
Polaris 600 (A)
Polaris 100 (B)
1050 W/m
2
Acceptable
Polaris 600 (A)
Polaris 600 (B)
Polaris 600 (C)
1800 W/m
2
Acceptable
Polaris 200 (A)
Polaris 200 (B)
Polaris 200 (C)
1800 W/m
2
Acceptable
Polaris 600 (A)
Polaris 600 (B)
Polaris 200 (C)
1800 W/m
2
Acceptable
Polaris 600 (A)
Polaris 200 (B)
Polaris 200 (C)
1800 W/m
2
Acceptable
Polaris 600 (A)
Polaris 600 (B)
Polaris 100 (C)
1650 W/m
2
Acceptable
Polaris 600 (A)
Polaris 100 (B)
Polaris 100 (C)
1500 W/m
2
Acceptable
Light combina-
tion
Maximum
total irradi-
ance
1)
[W/m
2
]
Recommended adjustment of the total irradi-
ance
2)
by reducing the illuminance
Thermal radiation in
the wound site after
adjustment of the
total irradiance
(B)
(A)
(A) (B) (C)
(A) (B) (C)
(C)
(A) (B)
(C)
(A)
(B)
(C)
(A) (B)
(C)
(A)
(B)
