4.0 Horizon Compact Management
The Horizon Compact system can be fully managed locally or remotely. Horizon Compact supports Telnet
access, SNMP management and a Web interface accessible through the IP network. The entire
Command Line Interface (CLI) command set is available through Telnet. The entire list of system
parameters is available through SNMP access. The Web interface provides access to system
configuration and performance parameters.
Management traffic can be configured as in-band or out-of-band.
In-band management traffic is via Port 1. Out-of-band management traffic is via Port 2.
To configure the management interface use the following procedure :
Procedure 4-1
Configuring Network Management Interface
Required Action Steps
login Log in as the Super User.
set network management
interface
sets the type of network management interface
Sequence :
set network management interface [port1/port2/port2 extended]
press Enter
Select port1 for in-band management, port2 for out-of-band
management and port2 extended for out-of-band management of the
far end Horizon Compact unit.
The system responds:
Network management interface is set to : [port1/port2/port2 extended]
save mib
Saves the MIB to RAM. Perform this command to save configuration
changes to non-volatile memory.
Sequence:
save mib press Enter
The system responds:
MIB saved successfully.
