DragonWave Inc. 48
Horizon Compact Release 1.01.00 Wireless Ethernet Product User Manual – Volume 2
3.5.2 Asymmetric Throughput Speed
Asymmetric throughput can be achieved by installing the same Horizon Compact hardware type at each
end of the link, and configuring one end with a different system speed. Note, that the System Mode, must
be identical at each end of the link for this to work. The variable will be the system speed figure.
Procedure 3-6
Configure Horizon Compact Throughput Speed (Asymmetric)
Required Action Steps
login Log in as a NOC user.
get system mode
Returns the current system mode and a list of available system
modes.
Sequence:
get system mode press Enter
System responds:
Current system mode is :hc50_67_qpsk (Example)
System modes available in the system:
cw_test hc50_67_qpsk hc50_110_16qam
hc50_171_32qam hc50_215_64qam hc50_271_128qam
hc50_322_256qam hc50_371_256qam
set system mode
Sets the system mode (channel bandwidth, maximum throughput
speed and modulation scheme).
Sequence:
set system mode <hc[bandwidth]_[throughput]_[modulation]>
Example:
set system mode hc50_110_16qam press Enter
(50 MHz channel bandwidth, 110 Mbps throughput and 16QAM
modulation.
System responds:
System mode set to :hc50_110_16qam
Note: For asymmetric speeds, the system mode must be set identically
at each end of the link.
