Aligning the Horizon Compact System

Horizon Compact Release 1.01.00 Wireless Ethernet Product User Manual – Volume 2

Figure 2-4 Typical main lobe coverage using 23 GHz Radio with 24” antenna

Table 2-2 Approximate size of beam at destination

Beamwidth 1 km 3 km 5 km 8 km 10 km

2˚

(18/24” antenna) 35m 105m 175m 280m 350m

1.3˚ (36” antenna) 23m 68m 114m 182m 227m

1˚

(48” antenna) 18m 54m 90m 144m 175m
