Horizon Compact Release 1.01.00 Wireless Ethernet Product User Manual – Volume 2
Procedure 4-10
Radio Loopback
Required Action Steps
login using NOC account
Log in as a NOC account
get radio loopback
Returns the status of the radio loopback feature.
Sequence:
get radio loopback
The system responds:
radio loopback is [on/off][time][network]
set radio loopback Enables and disables the radio loopback option. This feature allows
the radio transmitter and receiver system to be tested. In one option
the data signal is dropped and the radio signal alone is looped back. In
the second option, the data as well as the radio signal is looped back.
When in loopback, if no loss of synch alarm is raised, then this
indicates that the radio transmit and receive portions of the system are
working correctly. Note that this command is service affecting.
The default time limit before the loopback is automatically removed is
set to 30 seconds. Setting the time parameter to zero (0) maintains the
loopback in place indefinitely, until it is turned off.
Sequence :
set radio loopback [on/off] [time][network] press Enter
Where time is in seconds
Option 1
set radio loopback on press Enter
Radio loopback only with default time limit
set radio loopback on 45 network press Enter
Radio and network loopback initiated with a timeout period of 45
seconds
The system responds (Example) :
This may affect user traffic. Continue? Enter Y (Yes) or N (No) Y
Radio loopback is on 45 network
NOTE: setting the time to zero (0) will maintain the loopback
condition on indefinitely. To stop the loopback, issue the
following command:
set loopback off press Enter
