DragonWave Inc. 46
Horizon Compact Release 1.01.00 Wireless Ethernet Product User Manual – Volume 2
Required Action Steps
get system mode
Returns the current system mode and a list of available system
modes.
Sequence:
get system mode press Enter
System responds:
Current system mode is :hc50_67_qpsk (Example)
System modes available in the system:
cw_test hc50_67_qpsk hc50_110_16qam
hc50_171_32qam hc50_215_64qam hc50_271_128qam
hc50_322_256qam hc50_371_256qam
set system mode
Sets the system mode (channel bandwidth, maximum throughput
speed and modulation scheme). You can only select any one of the
modes shown as available when the get system mode command is
used.
Sequence:
set system mode <hc[bandwidth]_[throughput]_[modulation]>
Where [bandwidth] is the channel bandwidth of the configured
radio band; [throughput] is the maximum throughput capability in
Mbps; [modulation] is the modulation scheme.
Example:
set system mode hc50_67_qpsk press Enter
(50 MHz channel bandwidth, 67 Mbps throughput and QPSK
modulation.
System responds:
System mode set to :hc50_67_qpsk
save mib
Saves the MIB to RAM. Perform this command to save setting
changes to non-volatile memory.
Sequence:
save mib press Enter
The system responds:
MIB saved successfully.
