Advanced Configuration Features

Horizon Compact Release 1.01.00 Wireless Ethernet Product User Manual – Volume 2

Procedure 3-19

Configuring Single Wire Redundancy

Required Action Steps

Configure all 4 units the

same unless indicated

otherwise

Confirm that alignment mode

is OFF

Redundancy will not function if the alignment mode for the BNC

connector is enabled. This must be disabled.

Sequence:

set alignment mode off press Enter

The system responds:

Alignment mode is off

Network management For 1-wire mode we need to configure primary units for out-of-band

management via port2 and secondary units for in-band management

via port1

FOR A PRIMARY UNIT-

Sequence:

set network management interface port2 press Enter

The system responds:

Network management interface is set to : port2

FOR A SECONDARY UNIT-

Sequence:

set network management interface port1 press Enter

The system responds:

Network management interface is set to : port1

Redundancy mode This command sets the redundancy mode for either a primary or

secondary unit, with either 1-wire or 2-wire hardware configuration.

Since we are configuring a 1-wire system, use the following:

FOR A PRIMARY UNIT-

Sequence:

set redundancy mode primary_hsb_1wire

Note: hsb = hot stand-by

The system responds:

FOR A SECONDARY UNIT-

Sequence:

set redundancy mode secondary_hsb_1wire

The system responds:
