CH 6/ Advanced Setup Options
Journal
Parameter List
(continued)
Continued on next page
User Specified Frequency
User Specified Volts User Specified Amps
User Selected Voltage Harmonic 1 User Selected Current Harmonic 1
User Selected Voltage Harmonic 2 User Selected Current Harmonic 2
User Selected Voltage Harmonic 3 User Selected Current Harmonic 3
User Selected Voltage Harmonic 4 User Selected Current Harmonic 4
Unbalance
Sequence Unbalance Imbalance
Positive Sequence Voltage V Unbalance (RMS/RMS Avg) V RMS Imbalance
Negative Sequence Voltage V Unbalance (S2/S1) I RMS Imbalance
Zero Sequence Voltage V Unbalance (S0/S1)
Positive Sequence Current I Unbalance (RMS/RMS Avg)
Negative Sequence Current I Unbalance (S2/S1)
Zero Sequence Current I Unbalance (S0/S1)
Advanced Power
Arithmetic Power Vector Power
Arithmetic Sum PF Vector Sum PF
Arithmetic Sum DPF Vector Sum DF
Arithmetic Sum VA Vector Sum VA
Fund. Arithmetic Sum VA Fund. Vector Sum VA
