CH 1/ Getting Started
PX5 Controls, Indicators, and Connectors
Dimensions
PX5 is a self-contained, portable instrument weighing less than 5 pounds and
measuring 8" (20.3 cm) deep by 12" (30.5 cm) wide by 2.5" (6.4 cm) high. This section
identifies and describes the controls, indicators, and connectors on all sides of the PX5,
shown with rubber boot installed.
Top View
Front View
Rear View
Bottom View
SLOT 1
SLOT 2
