7-6
Event Activity Graph
Event Activity Graph
Event graph
description
The event graph is located on the top section of the event screen (see page 7-5). Four
timelines represent all events recorded from the time monitoring started. Events for
voltage channels are displayed above the grid and current channels are displayed below
the grid.
