8-15
CH 8/ Reports
Min/Max Table for Power Frequency and RMS Voltage
Min/Max table
The Min/Max table displays the minimum and maximum values for Power Frequency
and RMS Voltage along with the time and date of occurrence. Maximum phase values
of Rapid Voltage Change, Flicker, Supply Voltage Unbalance, and Harmonic are also
displayed along with time and date of occurrence.
From the Compliance Statistics bar chart screen on page 8-8, press Min/Max. The Min/
Max table will appear as shown below.
MARK476
MARK477
press to show Harmonic
values up to order no. 25
