Page #214 background image
B-2
General
General
Dimensions
Size
: 12” Width x 2.5” Height x 8” Depth (30 x 6. 4 x 20.3 cm)
Weight
: 4.2 pounds (1.9 kg)
Environmental
Operating
: 0 to 50 °C (32 to 122 °F)
Storage
: -20 to 55 °C (4 to 131 °F)
Humidity
: 95% non-condensing
System Time
Clock
Crystal controlled. 1 second resolution.
Event time clock displays to 1 msec resolution
Time displayed in analog or digital (12 or 24 hour) format
Accurate to 60 seconds per month.
Compact Flash
Memory Card
Sizes range from 32MB to 128MB
Power
Requirements
Use external UL/CE approved battery charger with international plugs. Mechanical On/
Off switch shuts unit down, but allows battery to continue to charge with switch in the
Off position.
Vo lt ag e
: 90-265V AC, 47/63 Hz, 120-175 V DC
Consumption
: 20 watts max
Field replaceable batteries
: More than 2 hours run-time (3 hours typical) when fully
charged.
Input resistance
Voltage input
: 16 MLine to Line
Current input
: 400 k
