F-3
APPENDIX F/ Event Classification
Range of
Variations as per
IEEE, IEC, and
Dranetz-BMI
(continued)
IEEE 1159 IEC 61000-4-30
(deviations from IEEE
1159 only are noted)
Dranetz-BMI
Waveform Distortion (measured as steady state values from 10/12 cycle
calculations)
DC Offset
frequency range
magnitude
Harmonics
frequency range
magnitude
Interharmonics
frequency range
magnitude
Notching
frequency range
magnitude
Noise
frequency range
magnitude
0 - 0.1%
DC - 100th
0 - 20%
0 - 6 KHz
0 - 2%
35 KHz
Broadband
0 - 1%
