Vigor2620 Series User’s Guide
63
Detect – Click it to detect a suitable MTU value
Accept – After clicking it, the detected value will be
displayed in the field of MTU.
PPP/MP Setup PPP Authentication – Select PAP only or PAP or CHAP for
PPP.
IP Assignment (IPCP) - Usually ISP dynamically assigns IP
address to you each time you connect to it and request. In
some case, your ISP provides service to always assign you the
same IP address whenever you request. In this case, you can
fill in this IP address in the Fixed IP field. Please contact your
ISP before you want to use this function.
Fixed IP Address– Type in a fixed IP address in the box.
WAN IP Alias - If you have multiple public IP addresses and
would like to utilize them on the WAN interface, please use
WAN IP Alias. You can set up to 8 public IP addresses other
than the current one you are using.
Dial-Out Schedule You can type in four sets of time schedule for your request.
All the schedules can be set previously in Applications >>
Schedule web page and you can use the number that you
have set in that web page.
PPPoE Pass-through The router offers PPPoE dial-up connection. Besides, you
also can establish the PPPoE connection directly from local
clients to your ISP via the Vigor router. When PPPoA protocol
is selected, the PPPoE package transmitted by PC will be
transformed into PPPoA package and sent to WAN server.
Thus, the PC can access Internet through such direction.
For Wired LAN – If you check this box, PCs on the same
network can use another set of PPPoE session (different with
the Host PC) to access into Internet.
For Wireless LAN – It is available for n model. If you check
this box, PCs on the same wireless network can use another
set of PPPoE session (different with the Host PC) to access
into Internet.
