Vigor2920 Series User’s Guide
134
Item Description
server if you enable PPTP/L2TP client mode.
Specify Gateway IP Address – Specify the gateway IP
address for DHCP server.
ISP Access Setup
Username -Type in the username provided by ISP in this field.
Password -Type in the password provided by ISP in this field.
Index (1-15) in Schedule Setup - You can type in four sets of
time schedule for your request. All the schedules can be set
previously in Application – Schedule web page and you can
use the number that you have set in that web page.
MTU
It means Max Transmit Unit for packet. The default setting is
1442.
PPP Setup
PPP Authentication - Select PAP only or PAP or CHAP for
PPP.
Idle Timeout - Set the timeout for breaking down the Internet
after passing through the time without any action.
IP Address Assignment
Method(IPCP)
Fixed IP - Usually ISP dynamically assigns IP address to you
each time you connect to it and request. In some case, your ISP
provides service to always assign you the same IP address
whenever you request. In this case, you can fill in this IP
address in the Fixed IP field. Please contact your ISP before
you want to use this function. Click Yes to use this function
and type in a fixed IP address in the box.
WAN IP Alias - If you have multiple public IP addresses and
would like to utilize them on the WAN interface, please use
WAN IP Alias. You can set up to 8 public IP addresses other
than the current one you are using.
Fixed IP - Usually ISP dynamically assigns IP address to you
