Vigor2920 Series User’s Guide
279
Available settings are explained as follows:
Item Description
Enable
Check to enable such function.
Bind Type
There are three types of bind type supported.
Simple Mode – Just simply do the bind authentication without
any search action.
Anonymous – Perform a search action first with Anonymous
account then do the bind authentication.
Regular Mode– Mostly it is the same with anonymous mode.
The different is that, the server will firstly check if you have
the search authority.
For the regular mode, you’ll need to type in the Regular DN
and Regular Password.
Server Address
Enter the IP address of LDAP server.
Destination Port
Type a port number as the destination port for LDAP server.
Use SSL
Check the box to use the port number specified for SSL.
Regular DN
Type this setting if Regular Mode is selected as Bind Type.
Regular Password
Specify a password if Regular Mode is selected as Bind
Type.
