Vigor2920 Series User’s Guide
309
Item Description
Backup Profile List
Set to Factory Default - Click to clear all VPN TRUNK-VPN
Backup mechanism profile.
No – The order of VPN TRUNK-VPN Backup mechanism
profile.
Status - “v” means such profile is enabled; “x” means such
profile is disabled.
Name - Display the name of VPN TRUNK-VPN Backup
mechanism profile.
Member1 - Display the dial-out profile selected from the
Member1 drop down list below.
Member2 - Display the dial-out profile selected from the
Member2 drop down list below.
Active - “Yes” means normal condition. ”No” means the state
might be disabled or that profile currently is set with Dial-in
mode (for call direction) in LAN-to-LAN.
Type - Display the connection type for that profile, such as
IPSec, PPTP, L2TP, L2TP over IPSec (NICE), L2TP over
IPSec(MUST) and so on.
Advanced – This button is only available when there is one
profile (or more) created in this page.
Detailed information for this dialog, see later section -
Advanced Backup.
General Setup
Status- After choosing one of the profile listed above, please
click Enable to activate this profile. If you click Disable, the
selected or current used VPN TRUNK-Backup/Load Balance
mechanism profile will not have any effect for VPN tunnel.
Profile Name- Type a name for VPN TRUNK profile. Each
profile can group two VPN connections set in LAN-to-LAN.
The saved VPN profiles in LAN-to-LAN will be shown on
Member1 and Member2 fields.
Member 1/Member2 - Display the selection for LAN-to-LAN
dial-out profiles (configured in VPN and Remote Access >>
LAN-to-LAN) for you to choose for grouping under certain
VPN TRUNK-VPN Backup/Load Balance mechanism profile.
No - Index number of LAN-to-LAN dial-out profile.
Name - Profile name of LAN-to-LAN dial-out profile.
Connection Type - Connection type of LAN-to-LAN
dial-out profile.
