Vigor3900 Series User’s Guide
85
Available parameters are listed as follows:
Item Description
Profile
Type the name of the LAN profile.
Enable This Profile
Check this box to enable such profile.
Description
Type the description for the new LAN profile.
VLAN ID
Type a number as the VLAN ID to make the data be
identified while performing data transmission.
Default MAC
Address
Enable – Click it to enable the default MAC address for
such profile.
Disable – Click it to type the MAC address manually for
such profile.
MAC Address
If Default MAC address is disabled, please specify a MAC
address from the drop down list for such profile.
IPv4 Protocol
Display the type for the IPv4 protocol for such profile.
Mode
Choose NAT or ROUTING as the operation mode for such
profile.
IP Address
Type the IP address of the router for the LAN profile.
Subnet Mask
Use the drop down list to choose a suitable mask for the
LAN profile.
Gateway IP
Address
Such IP address is ready for matching with the function of
Virtual System.
– click the icon to clear the IP setting.
2
nd
Subnet
Specify one 2
nd
subnet which might be needed in the future.
