Vigor3900 Series User’s Guide
86
Add – Click it to add a new subnet mask with IP address and
specified mode.
Save – Click it to save the settings.
IP – Type the IP address if you click Add for adding a new
entry.
Subnet Mask – Use the drop down list to choose the one
you want.
Mode – Specify NAT or Routing as the mode.
– click the icon to remove the selected entry.
IPv6 Protocol
It defines the IPv6 connection types for LAN interface.
Possible types contain Link-Local, Static and DHCP-SLA.
Except Link-Local, each type requires different parameter
settings.
Link-Local- Link-Local address is used for communicating
with neighbouring nodes on the same link. It is defined by
the address prefix fe80::/10. You don't need to setup
Link-Local address manually for it is generated
automatically according to your MAC Address.
Static –This type allows you to setup static IPv6 address for
LAN.
DHCP-SLA- DHCPv6 client mode would use IA_NA
option of DHCPv6 protocol to obtain IPv6 address from
server.
IPv6 Address
If Static is chosen as IPv6 Protocol, please type the IPv6
address in this field.
IPv6 Prefix Length
Display the IPv6 prefix length.
DHCPv6 SLA
WAN Interface
If DHCP-SLA is chosen as IPv6 Protocol, please choose one
of the WAN profiles in this field.
DHCPv6 SLA ID
The ID number set here is used by an individual organization
to create its own local addressing hierarchy and to identify
subnets.
Apply
Click it to save and exit the dialog.
Cancel
Click it to exit the dialog without saving anything.
