Vigor3900 Series User’s Guide
87
3. When you finish the above settings, please click Apply to save the configuration and
exit the dialog.
D
D
H
H
C
C
P
P
In the Vigor3900 router, there are some IP address settings for the LAN interface. The IP
address/subnet mask is for private users or NAT users. The IP address of the default gateway
on other local PCs should be set as the Vigor3900 server IP address. When the DSL
connection between the DSL and the ISP has been established, each local PC can directly
route to the Internet. The IP address/subnet mask can also be used to connect to other private
users (PCs). On this page you will see the private IP address defined in RFC-1918. Usually
we use the 192.168.1.0/24 subnet for the route.
Each item will be explained as follows:
Item Description
Edit
Modify the selected LAN profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
rule.
Refresh
Renew current web page.
Profile
Display the name of the LAN profile.
