Available settings are explained as follows:
Item Description
SSID/Security Key Once the access point specified above, the name / security key of the
AP will be shown automatically in these fields.
Channel
Means the channel frequency of the wireless LAN. You may switch
channel if the selected channel is under serious interference.
Security Mode There are several modes provided for you to choose. Each mode will
bring up different parameters (e.g., WEP keys, Pass Phrase) for you to
configure.
Encryption Type Available options will vary according to the selected Security Mode.
When Open is selected:
 Choose None to disable the WEP Encryption. Data sent to the AP
will not be encrypted.
 WEP Keys –To enable WEP encryption for data transmission,
please choose WEP. Four keys can be entered here, but only one
key can be selected at a time. The format of WEP Key is restricted
to 5 ASCII characters or 10 hexadecimal values in 64-bit
encryption level, or restricted to 13 ASCII characters or 26
hexadecimal values in 128-bit encryption level. The allowed
content is the ASCII characters from 33(!) to 126(~) except '#' and
','.
When Shared is selected:
 WEP Keys - To enable WEP encryption for data transmission,
please choose WEP. Four keys can be entered here, but only one
key can be selected at a time. The format of WEP Key is restricted
to 5 ASCII characters or 10 hexadecimal values in 64-bit
encryption level, or restricted to 13 ASCII characters or 26
hexadecimal values in 128-bit encryption level. The allowed
content is the ASCII characters from 33(!) to 126(~) except '#' and
','.
When WPA/PSK or WPA2/PSK is selected:
 Select TKIP or AES as the algorithm for WPA.
 Security Key - Select WEP, TKIP or AES as the encryption
algorithm.
Type 8~63 ASCII characters, such as 012345678..(or 64
Hexadecimal digits leading by 0x, such as "0x321253abcde...").
