VigorSwitch G2240 User’s Guide
67
Ingress Unit: There are two units for ingress rate limit: kbps / Mbps
Egress Enabled: Shaper enabled to limit egress bandwidth by egress rate.
Egress Rate: The configurable shaper rate range:
500 Kbps ~ 1000000 Kbps
1 Mbps ~ 1000 Mbps
Egress Unit: There are two units for egress shaper rate limit: kbps / Mbps
2
2
.
.
6
6
.
.
4
4
S
S
t
t
o
o
r
r
m
m
C
C
o
o
n
n
t
t
r
r
o
o
l
l
Function name:
Storm Control Configuration
Function description:
The switch support storm ingress control function to limit the Flooded, Multicast and
Broadcast to prevent storm event happen.
Parameter description:
Port #: Port number.
Frame Type: There three frame types of storm can be controlled: Flooded
unicast / Multicast / Broadcast.
Status: The function means to enable the frame type for Storm
control.
Rate (pps): Refer to the following rate configurable value list, the unit is
Packet Per Second (pps).
1 / 2 / 4 / 8 / 16 / 32 / 64 / 128 / 256 / 512 / 1K / 2K / 4K /
8K / 16K / 32K / 64K / 128K / 256K / 512K / 1024K
To Next Page
