30
VAPOR-LOGIC
®
VERSION 6 INSTALLATION AND OPERATION MANUAL
INSTALLATION
Step 2 – Setup
Table 30-1:
Settings menu (continued)
Menu item Default value
Minimum
value
Maximum
value
Units Notes
Fan Dispersion
Fan Type -- -- -- --
Space Distribution
Unit
-- -- -- --
Fan Off Delay 5 1 30 Minutes
Area-Type Fan -- -- -- --
Auxiliary Temperature Sensor
Purpose Not Used -- -- --
Temperature
Compensation
-- -- -- --
Sensor Offset
0 -20 20 °F
0 -11 11 °C
Temperature
Monitoring
-- -- -- --
Sensor Offset
0 -20 20 °F
0 -11 11 °C
Not Used -- -- -- --
Programmable Outputs
Dry Contact 1 or 2 -- -- -- --
CAUTION
Programmable dry contact maximum current
Programmable dry contact (P12 or P16) is rated for 125 VAC,
3 AMP or 30 VDC, 3 AMP maximum. Exceeding this maximum
rating can cause the dry contact (relay) component or the Vapor-
logic board to fail.
Contact Behavior
Normally
open
Normally
open
Normally
closed
-- Contact action on event
Contact Purpose Default Alerts -- -- --
Default Alerts
View Default
Alerts
-- -- -- --
A dry contact activates whenever there is an alert,
which does not auto-clear.
Selected Alerts
Alert selection
-- -- -- --
A dry contact activates whenever there are alerts selected from
the alert selection list.
Alert on Low RH -- -- -- --
Alert below RH 50 0 100 --
Contact toggles whenever the space humidity falls below the low
RH setting. Adjust the contact behavior to either open or close
when the space RH gets low. To use this feature the control input
signal type must be an RH transmitter.
Steam Yes/No -- -- -- --
A dry contact activates when the tank temperature reaches
boiling
Heat On/Off -- -- -- -- A dry contact activates when the humidifier is heating.
Not Used -- -- -- --
