72
VAPOR-LOGIC
®
VERSION 6 INSTALLATION AND OPERATION MANUAL
Modbus, BACnet, LonTalk interoperability
OPERATION
Table 72-1:
GTS humidifier LX series interoperability variable and object names (continued)
Variable name and
BACnet object name
Read Only
(RO) or
Read Write
(RW)
Modbus
register
number*
BACnet
Object
Type and
Instance
LonTalk variable
names**
Description
Units Range
I-P units SI units I-P units SI units
Faults and alarms (continued)
Burner 2 fault RW
DV-21
21
BV-21 nvoAlrmBurner2
See Table 49-1,
Alarms menu
-- -- -- --
Ignition module 1 fault RW
DV-24
24
BV-24 nvoAlrmIgnitMod1
Ignition module 2 fault RW
DV-25
25
BV-25 nvoAlrmIgnitMod2
Blower 1 fault RW
DV-28
28
BV-28 nvoAlrmBlower1
Blower 2 fault RW
DV-29
29
BV-29 nvoAlrmBlower2
Gas valve 1 fault RW
DV-32
32
BV-32 nvoAlrmGasValve1
Gas valve 2 fault RW
DV-33
33
BV-33 nvoAlrmGasValve2
Low water RW
DV-36
36
BV-36 nvoAlrmLowWater
Replace ignitors! RW
DV-37
37
BV-37 nvoAlrmFoaming2
* See Note 1 on Page 73.
** See Note 2 on Page 73.
Continued
