DRI-STEEM XT Series Electrode Steam Humidifier Installation, Operation, and Maintenance Manual • Page 43
Wiring the XT Steam Blower
Power is provided to the XT Steam Blower from the humidifier
blower terminals. Connect the L1 line from the steam blower to
the L1 humidifier blower terminal; and connect L2 from the steam
blower to the L2 humidifier blower terminal. Connect ground to the
ground terminal. Be sure to tighten terminals securely.
Dispersion: XT Steam Blowers
(continued)
Table 43-1:
XT Steam Blower specifications
Steam
blower
model
Maximum capacity Shipping weight Operating weight
Amps at
115V
(50/60 Hz)
Input
power
Volume airflow Noise
lbs/hr kg/h lbs kg lbs kg A W cfm m
3
/min dBA*
XTSB-20 20 9.1 12 5.4 10 4.5 0.25 29 63 1.8 49
XTSB-50 50 22.7 25.5 11.6 23.2 10.5 0.74 85 500 14.2 53
Notes:
* Measurement taken 6.5 ft (2 m) in front of steam blower cabinet
Steam blowers ship separately from XT humidifiers.
