Page 66 • DRI-STEEM XT Series Electrode Steam Humidifier Installation, Operation, and Maintenance Manual
Replacement parts (cont.)
Table 66-1:
XT Series replacement parts
No. Description Part no.
Hoses, adaptors, and clamps
1
Hose, steam 22/29 mm × 12.00 (XT-10/20 except XT-20 208/240V/1-Ph) 530002-012
Hose, steam 35/43 mm × 12.00 (XT-20 208/240V/1-Ph, XT-30/50/75/100/150/200) 530003-012
2
Adaptor, 7/8" to 1-1/2" (XT-10/20 except XT-20 208/240V/1-Ph) 162774-005
Adaptor, 1-3/8" to 1-1/2" (XT-20 208/240V/1-Ph, XT-30/50/75/150) 162774-010
Adaptor, 1-3/8" to 1-1/2" (XT-100/200) 162715-002
3
Hose clamp, steam hose to adaptor (XT-10/20 except XT-20 208/240V/1-Ph) 700560-075
Hose clamp, steam hose to adaptor (XT-20 208/240V/1-Ph, XT-30/50/75/100/150/200) 700560-125
4 Hose, drain 22/29 mm × 10.00 530005-010
5
Hose clamp D29, drain cup, and steam cylinder to steam hose (XT-10/20 except XT-20 208/240V/1-Ph) 530001-051
Hose clamp D43, steam cylinder to steam hose (XT-20 208/240V/1-Ph, XT-30/50/75/100/150/200) 530001-052
Electrical
6 Switch, main on-off 530010-001
7 Switch, door interlock 530010-002
8
Transformer, 208/240/480 to 24 VAC 408965-001
Transformer 277 to 24 VAC 408982
Transformer, 600 to 24 VAC 408986
9
Contactor, type 3RT1023 (except XT-20 208/240V/1-Ph) 530010-004
Contactor, type 3RT1035 (XT-20 208/240V/1-Ph) 530010-024
9A Rectifier (XT-20 208/240V/1-Ph) 530010-025
10 Plug, max. water level sensor 530010-005
11 Plug, electrode 530010-006
12 Fuse, 6.3 A 530010-007
13
Terminal 4 mm2 (XT-10, XT-20 480-600V/1-Ph, XT-20 208/240/480/600V/3-Ph, XT-30 600V/3-Ph) 530010-010
Terminal 6 mm2 (XT-30 480V/3-Ph) 530010-011
Terminal 10 mm2 (XT-20 277V/1-Ph, XT-30 208-240V/3-Ph, XT-50 480-600V/3-Ph, XT-75, XT-150) 530010-012
Terminal 16 mm2 (XT-20 208-240V/1-Ph, XT-50 208-240V/3-Ph, XT-100, XT-200) 530010-018
14
Ground terminal 4 mm2 (XT-10, XT-20 480-600V/1-Ph, XT-20 208/240/480/600V/3-Ph, XT-30 600V/3-Ph) 530010-013
Ground terminal 6 mm2 (XT-30 480V/3-Ph) 530010-014
Ground terminal 10 mm2 (XT-20 277V/1-Ph, XT-30 208-240V/3-Ph, XT-50 480-600V/3-Ph, XT-75, XT-150) 530010-015
Ground terminal 16 mm2 (XT-20 208-240V/1-Ph, XT-50 208-240V/3-Ph, XT-100, XT-200) 530010-019
15 Terminal, safety and optional blower 530010-017
16
Transformer, current sensing (208/240/277V units, except XT-20 208/240V/1-Ph) 530010-021
Transformer, current sensing (XT-20 208/240V/1-Ph) 530010-023
Transformer, current sensing (480/600V units) 530010-022
17 Board, supply 24V 530010-030
18
Board, processor 24V (XT-10/20/30/50/75/100) 530010-031
Board, processor 24V (XT-150/200) 530010-034
More on next page ▶
