DSC Touch-SCW9067 User Manual

TROUBLESHOOTING
PANEL TEST TROUBLESHOOTING
FIND IT
Settings
System Tests
Panel Test
Installer Code Access
Master Code Access
DSC Confidential and Proprietary Page of 98 114
© Last updated 4/29/15 All rights reserved
Test
Description
If fails:
Arm-Disarm
Tests the arm/disarm
operation
Reboot panel, run test again then if necessary perform a
master reset and repeat test.
Camera
Tests panel camera operation
Reboot panel, run test again then if necessary perform a
master reset and repeat test.
Photos
Checks that photos are loaded
in the photo frame app
1) Go to Apps -> Photo Frame -> Add Photos
2) Add photos from Wifi photo sets or an SD card.
Help Videos
Checks help videos are
installed in the panel.
1) Go to Settings -> Load Help Videos
2) Load All the Help videos in SD card and insert it into panel
3) Add the selected files from SD card to help videos list on
the panel.
Battery
Checks panel battery health
1) Make sure the battery is connected.
2) If test continues to fail, replace the battery.
LCD On/Off
Checks panel's LCD screen
operation.
1) Reboot the panel and repeat the test.
2) If this test continues to fail, LCD may be faulty
If you run a panel test and it fails, use the following steps to fix the issue.
