DSE DSE890 - Gps Connector

Specifications
057-165 ISSUE: 9.0
Page 10 of 53
2.7 GPS CONNECTOR
NOTE: GPS service is not available with DSE891 Ethernet Gateway.
DSE890 GPS Connector
Required Antenna Cable Connector
GPS
SMA MALE
(Inside thread, male central pin)
SMA FEMALE
(Outside thread, female central receptacle)
NOTE: DSE stock a GPS antenna suitable for this purpose. Part number 020-130.
NOTE: DSE stock a Combined GSM/GPS antenna suitable for this purpose.
Part number 020-150.
DSE testing has shown that separate GSM and GPS antennae tend to give better results than a
combined antenna where a clear view of the sky is not available.
