7 MAINTENANCE, SPARES, REPAIR, AND SERVICING
The module is designed to be Fit and Forget. As such, there are no user serviceable parts. In the
case of malfunction, contact your original equipment supplier (OEM).
If additional plugs are required, please contact the DSE Sales department using the part numbers
below.
Module Terminal Designation
Description
Part No.
1-6
6 way 5.08mm
007-446
A B SCR
3 way 5.08mm
007-174
If antennae or USB cables are required, please contact the DSE Sales department using the part
numbers below.
Connection
Description
Part No.
USB
USB A to USB B (DSEGateway
®
to host controller)
016-125
GSM
(DSE890 3G only)
GSM Antenna
020-141
GPS
(DSE890 3G only)
GPS Antenna
020-130
GSM & GPS
(DSE890 3G only)
Combined GSM and GPS Antenna
020-150
8 WARRANTY
DSE provides limited warranty to the equipment purchaser at the point of sale. For full details of any
applicable warranty, contact the original equipment supplier (OEM).
9 DISPOSAL
9.1 WEEE (WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT)
Electrical and Electronic equipment must be stored, collected, treated, recycled and
disposed of separately from other waste.
