DSE DSE890 - DIMENSIONS AND MOUNTING

Specifications
Page 13 of 53
057-165 ISSUE: 9.0
2.12 DIMENSIONS AND MOUNTING
Overall Size
85 mm x 149 mm x 51 mm
(3.35” x 5.85” x 2.01”)
Weight
120 g
(4.23 oz.)
Mounting Type
DIN rail or chassis mounting
DIN Rail Type
EN 50022 35 mm type only
Mounting Holes
M4 clearance
Mounting Hole Centres
73 mm x 137 mm
(2.89” x 5.39”)
BS EN 60529
(Degrees Of Protection Provided By
Enclosures)
IP21
UL508
Nema Rating
Enclosure type 1 (indoor use only)
Dimensions in mm
