Conflicts for the Slave DSP Bit I/O Unit
The following I/O features of the DS1104 conflict with the
Slave DSP Bit I/O unit:
Slave DSP Bit I/O Unit *)
Signal
Conflicting I/O Feature **)
Bit
(RTI)
Bit
(RTLib)
Ch
(RTI)
Ch
(RTLib)
Conflicts Concerning Single Bits
Bit 0 Group 2, bit 0 SPWM7 • PWM Ch 2 Ch 2
• External Trigger
Bit 1 Group 2, bit 1 SPWM8 • PWM Ch 3 Ch 3
• External Trigger
Bit 2 Group 2, bit 2 SPWM9 • PWM Ch 4 Ch 4
• External Trigger
Bit 3 Group 2, bit 3 ST1PWM • Slave DSP PWM int
• External Trigger
Bit 4 Group 2, bit 4 ST2PWM • PWM • Ch 1 • Ch 1
•D2F •Ch 4 •Ch 4
• External Trigger
Bit 5 Group 2, bit 5 ST3PWM External Trigger
Bit 6 Group 3, bit 4 SCAP1 PWM2D/F2D Ch 1 Ch 1
Bit 7 Group 3, bit 5 SCAP2 PWM2D/F2D Ch 2 Ch 2
Bit 8 Group 3, bit 6 SCAP3 PWM2D/F2D Ch 3 Ch 3
Bit 9 Group 3, bit 7 SCAP4 PWM2D/F2D Ch 4 Ch 4
Bit 10 Group 4, bit 0 SCLK SPI –
Bit 11 Group 4, bit 1 SSTE SPI –
Bit 12 Group 4, bit 2 SSIMO SPI –
Bit 13 Group 4, bit 3 SSOMI SPI –
*) Related RTI blocks and RTLib
functions:
• DS1104SL_DSP_BIT_IN_Cx/
DS1104SL_DSP_BIT_OUT_Cx
• See Slave DSP Bit I/O Unit in
the DS1104 RTLib Reference
**) Related RTI blocks and RTLib functions:
PWM:
• DS1104SL_DSP_PWM
•See Slave DSP PWM Generation in the DS1104 RTLib Reference
Slave DSP PWM int
• DS1104SLAVE_PWMINT
•See ds1104_slave_dsp_pwm3_int_init in the DS1104 RTLib Reference
D2F:
• DS1104SL_DSP_D2F
•See Square Wave Signal Generation (D2F) in the DS1104 RTLib
Reference
PWM2D/F2D:
• DS1104SL_DSP_PWM2D/DS1104SL_DSP_F2D
•See Slave DSP PWM Measurement (PWM2D)/Square Wave Signal
Measurement (F2D) in the DS1104 RTLib Reference
SPI:
•See Slave DSP Serial Peripheral Interface in the DS1104 RTLib
Reference
