Incremental Encoder Interface
The DS1104 provides a digital incremental encoder interface with
input channels for two incremental encoders. The pins which make up
the inputs are called:
■ IDX(1), IDX(1)
, PHI90(1), PHI90(1), PHI0(1), PHI0(1)
■ IDX(2), IDX(2), PHI90(2), PHI90(2), PHI0(2), PHI0(2)
The incremental encoder interface supports single-ended TTL and
differential RS422 signals (selectable by software). For a feature
description of the encoder interface refer to Incremental Encoder
Interface in the DS1104 Features document.
For detailed information on connecting external devices to the
incremental encoder interface, refer to:
■ Input Circuit and Electrical Characteristics on page 130
■ Notes and Tips on Signal Conditioning on page 132
