dSPACE DS1104 User Manual

Mapping of I/O Signals ▲ ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■
■
DS1104 Hardware Installation and Configuration March 2004
I■■■■■■■■■■■■■ ▼
114
■■■■■■■■■■■■■■■▼
Conflicts for Slave DSP Square-Wave Signal
Generation (D2F)
The following I/O features of the DS1104 conflict with Slave DSP
Square-Wave Signal Generation:
Slave DSP Square-Wave
Signal Generation (D2F) *)
Signal
Conflicting I/O Feature **)
Ch
(RTI)
Ch
(RTLib)
Ch
(RTI)
Ch
(RTLib)
Conflicts Concerning Slave DSP Square-Wave Signal Generation as a Whole
• If you perform 3-phase or space vector PWM signal generation (PWM3 or PWMSV), you cannot generate square-wave
signals at the same time.
Conflicts Concerning Single Channels
Ch 4 Ch 4 ST2PWM • Slave DSP Bit I/O unit • Bit 4 • Group 2, bit
4
•PWM •Ch 1 •Ch 1
*) Related RTI blocks and RTLib
functions:
• DS1104SL_DSP_D2F
• See Square Wave Signal
Generation (D2F) in the
DS1104 RTLib Reference
**) Related RTI blocks and RTLib functions:
PWM3/PWMSV:
• DS1104SL_DSP_PWM3/DS1104SL_DSP_PWMSV
• See Slave DSP PWM3 Generation/Slave DSP PWMSV Generation in the
DS1104 RTLib Reference
Slave DSP Bit I/O Unit:
• DS1104SL_DSP_BIT_IN_Cx/ DS1104SL_DSP_BIT_OUT_Cx
• See Slave DSP Bit I/O Unit in the DS1104 RTLib Reference
PWM:
• DS1104SL_DSP_PWM
• See Slave DSP PWM Generation in the DS1104 RTLib Reference
