Ducati Scrambler - Page 188

To Next Page

To Previous Page

Pull out the headlight to the  sliding out the RH

U-bolt (E) from pin (F), and tilt it towards the front

mudguard.

Duly  it while loosening screws (4) of light

cover (5), and remove cover.

Fig 190

Fig 191

187
