14.4 Mathematical angle positions
The mathematical angle position is
indicated in the view from the bottom
on the driven shaft as shown in the
pictures above.
The mathematical angle position
of the stepped motor position 0° or
90° for the respective stepped mo-
tor type is indicated in the following
table:
SAD 15 SAD 1.2 WG
SAD 3.0 WG
SAD 10 WG
*1
SAD 1.5
SAD 3.0
(IP 40)
SAD 0.6
SAD 1.2
Reference point
"Standard":
270° / 0° 90° / 0° 270° / 166,63° 90° / 0°
Reference point
"Exchanged":
19° / 289° 81,5° / 341,5° 156,92° /
250,29°
341° / 71°
*1 : this version is not yet available
Attention!
All stepped motors must be
equipped with two mechanical stops.
• Lower mechanical stop between -7°
and -10°
• Upper mechanical stop between
92° and 95° or
upper mechanical stop between
95,5° and 98,5° for SAD1.5 and
SAD3.0 (IP 40)
The absolute stop positions depend
on the stepped motor and the se-
lected reference point (see table).
0° / 90° correspond to:
180°
90°
0°
(360°)
270°
