Printed in Germany • Edition 02.14 • Nr. 254 722
8 Parameters
8.5 P5x - Additional valve
Parameter
P5x
Designation Description Setting
P50 Additional valve:
Activation state
In the state dened here, the output
of the additional valve is activated.
Attention! The actual activation
can take place with a delay in time!
See also P52.
P51 Additional valve: De-
activation state
In the state dened here, the output
of the additional valve is deactivat-
ed.
Attention! The actual deactivation
can take place with a delay in time!
See also P53.
P52 Additional valve:
Time-delayed activa-
tion
Using this parameter, the time-
delayed activation is dened, that
means that the additional valve is
switched on a set time period after
the activation of the state dened in
P50.
Attention! If the duration of the
state is shorter than the dened
delay, the additional valve is only
activated with the start of the sub-
sequent state. For example, if the
state "Pre-aeration A" is set with a
delay in time of 40 seconds (P50
and P52), the pre-aeration time A,
however, (P60) lasts only 30 sec-
onds, the additional valve is al-
ready activated after 30 seconds
when the next state is started (e.g.
"pre-aeration B) and not 40 sec-
onds after the start of the state
"pre-aeration A".
P53 Additional valve:
Time-delayed deacti-
vation
Same function as P52, but with a
delay in time for the switch-o key.
