Printed in Germany • Edition 02.14 • Nr. 254 722
Reduces the power
Increases the power
set modulation percentage
Activation of the service display:
press the keys simultaneously
back to the
operational status display
Service display
The service display is activated out of the operational status display.
The service display can only be activated in the burner mode.
A heat request must be active on the temperature controller input.
Power setting by means of the ± keys
!!
In this mode, the device does not react to the power setting signal of the inputs Power [+] and
Power [-]
11.8 Service display
