Printed in Germany • Edition 02.14 • Nr. 254 722
5.3 Inputs
Designation Safety-
related
Type of input Electrical data MPA
5111
Extension Module
Flame
detector
● Ionisation Threshold value: approx.
1.2 µA
●
Air pressure
switch
●
Switching contact
(potential-free)
24V DC / 10 mA ●
Gas pressure
detector
●
Switching contact
(potential-free)
24V DC / 10 mA ●
Gas pressure
detector VPS
● Switching con-
tact (potential-
free)
24V DC / 10 mA ●
Safety chain ●
Switching contact
230V AC / max. 10 A ●
Temperature
controller
Switching contact
230V AC ●
Power controller
+/-
Switching contact
230V AC ●
Fan
speed
Hall sensor 24V DC ●
Exchangeable
backup fuse
Fuse 6.3 A slow-blow or 10 A
fast-blow
●
Remote unlocking
Switching contact
230V AC ●
Analogue set-
point
Plug ●
Cable length max. 10 m
Integrated function MPA-EM1/1 MPA-EM1/2 MPA-EM1/3 MPA-EM1/4
Display ● ● ● ●
TWI ● ● ● ●
Parameter record-stick - ● ● ●
0...10 V input - - ● ●
0...10 V output - - ● ●
4....20 mA input - - ● -
4...20 mA output - - ● -
Stepped motor output ● ● ● ●
{component protection / encapsu-
lated version}
● ● ● -
Type of wiring diagram A A A A
P18: Operating mode PWM output 0 0 11 8
P27: Modication method Modulation 0,1 0,1 0,1,2,3 0,1,2,3
5.4 Extension module
equipped with analogue inputs and
outputs (e.g. MPA-EM1/3):
Analogue outputs
0/2...10 V, load >= 2 kilo ohms
0/4...20 mA, load <= 500 kilo ohms
(Attention! The output must not con-
nected to GND!)
Analogue input
0/2...10 V, Imax = 0.5 mA
or
0/4...20 mA, apparent ohmic resist-
ance R <= 500 kilo ohms
The inputs and outputs are NOT
electrically isolated from the mains!
