Printed in Germany • Edition 02.14 • Nr. 254 722
5.1 General information
Rated voltage 230 V AC -15 % ... +10 %
Frequency 50 ... 60 Hz
Fuse MPA 5111 6.3 A slow-blow fuse or 10 A fast-blow fuse, integrated,
exchangeable
Type of protection IP 20
Ambient temperature 0 °C +60 °C
Humidity DIN 60730-1, no dewing admissible
Electrical connection Correct phase sequence and protective earth conductor according to the wiring dia-
gram
Mounting position as desired
Dimensions approx. 200 x 105 x 115 mm
The admissible cable length to the display is max. 3 m
The admissible cable length to the stepped motor is max. 3 m
5. Technical data
5.2 Outputs
Designation Safety-
related
Type of output Electrical data MPA
5111
Extension Module
Additional valve Y1 ● Relay contact 230 V AC / 2 A (∑ < 5 A) ●
Valve Y2 ● Relay contact 230 V AC / 2 A (∑ < 5 A) ●
Valve Y3 ● Relay contact 230 V AC / 2 A (∑ < 5 A) ●
Spark generator ● Relay contact 230 V AC / 3 A (∑ < 5 A) ●
Fan Relay contact 230 V AC / 4 A ●
PWM 1 (for ex.
fan)
PWM 24-31 V DC / 4 kHz ●
Fused mains
power supply
Main volltage 230 V AC / 4 A _ ●
Operation display Internally via V2 230 V AC / 1 A (∑ < 5 A) ●
Fault output Relay contact 230 V AC / 1 A ●
Supply
ame detector
Internally via
fan
230 V AC / 0.1 A ●
PWM 2 (e.g. 0...10
V)
for example
analogue
output
for example 0...10 V _ ●
PWM 3 (e.g. 4...20
mA)
for example
analogue
output
for example 4...20 mA _ ●
Stepped motor Plug ●
Display Plug ●
TWI communica-
tion
Plug ●
Cable length max. 10 m
The sum of the currents of all safety-related consumers must not exceed 5 A!
The sum of the currents of all consumers must not exceed 6.3 A (10 A)
